Detailed Description of II/224
|
||
Individual files can be fetched (via http) from
here
or via ftp from: ftp://cdsarc.u-strasbg.fr/pub/cats/II/224
The catalogue can be queried from: http://vizier.u-strasbg.fr/viz-bin/VizieR?-source=II/224
This standardized document follows the rules of the Standard Description for Astronomical Catalogues. For those having to work on this catalogue using FORTRAN programs, this ReadMe file can be transformed into a f77-compliant program which reads the files making up this catalogue, in two versions: either a f77 program loading whole files into arrays, or a f77-program reading each data file line by line.
II/224 Catalogue of Stellar Diameters (CADARS) (Pasinetti-Fracassini+ 2001)
================================================================================
Catalog of Apparent Diameters and Absolute Radii of Stars (CADARS)
(3rd Edition). Comments and statistics
Pasinetti-Fracassini L.E., Pastori L., Covino S., Pozzi A.
<Astron. Astrophys. 367, 521 (2001)>
=2001A&A...367..521P
================================================================================
ADC_Keywords: Stars, diameters
Keywords: catalogues - stars: fundamental parameters
Description:
For 9733 stars this catalog lists all values of the apparent and
absolute radii from the literature. Data were compiled beginning 1950
up to 1997.
The stars are listed according to the following order of
identification: HD number, DM number, variables with constellation
name in alphabetical order of the abbreviations, other identifications
in alphabetical order, LMC and SMC stars. The apparent magnitudes and
spectral types are those reported by the authors, as they are basic
data used in some methods for obtaining the stellar diameters.
The catalogue is followed by the lists of the Remarks and References.
Details and statistics will appear in A&A Suppl.
This version supersedes the previous editions by M.Fracassini, L.E.
Pasinetti, F. Manzolini (1981A&AS...45..145F, Cat. II/61); and M.
Fracassini, L.E. Pasinetti-Fracassini, L. Pastori and R. Pironi
(1988BICDS..35..121F, Cat. II/155)
File Summary:
FileName Lrecl Records Explanations
× ReadMe 80 . This file
× cadars.dat 98 13570 The Catalogue
× refs.dat 80 891 The References
× notes.dat 80 3925 Remarks
Byte-by-byte Description of file: cadars.dat
Bytes Format Units Label Explanations
1- 2 I2 h RAh ? Right Ascension J2000 (hours)
4- 5 I2 min RAm ? Right Ascension J2000 (minutes)
7- 10 F4.1 s RAs ? Right Ascension J2000 (seconds)
12 A1 --- DE- ? Declination J2000 (sign)
13- 14 I2 deg DEd ? Declination J2000 (degrees)
16- 17 I2 arcmin DEm ? Declination J2000 (minutes)
19- 20 I2 arcsec DEs ? Declination J2000 (seconds)
22- 30 A9 --- ID1 HD or BD number or other identification
31- 44 A14 --- ID2 Bayer, Flamsteed or other identification
G and S indicate components of binary system
46- 50 F5.2 mag Vmag *? Apparent visual magnitude
52- 65 A14 --- Sp MK Spectral type (from authors or SIMBAD)
66- 73 E8.2 arcsec Diam *? Apparent stellar diameter
76- 83 E8.2 solRad Rad *? Absolute radius
86- 87 A2 --- Meth Method of determination, see "Methods" section
89- 91 A3 --- r_Diam key to reference, see file refs.dat
94- 98 A5 --- rem *Remarks, see note and/or file notes.dat
Note on Vmag:
Apparent visual magnitude given by the Authors, otherwise by SIMBAD;
remarks (W) specify magnitudes in other wavelengths.
For variable stars: magnitude at maximum luminosity
Note on Diam:
Apparent diameter (arcsec) of the uniform disk.
Three significant figures are given; values given with more figures
are reported in the remarks (file "notes.dat"). Remarks specify other
cases and/or values corrected for the limb darkening (L): errors (E)
are given in Remarks for uniformity with the previous versions.
Note on Rad:
errors given in Remarks.
Averaged absolute radius are given for Cepheids (code 5, 5A, 5B).
Note on rem:
In the file "notes.dat", the star identifier is followed by the
code of the source. The remark codes are:
B = Spectroscopic binary
D = Double star
G = Cluster, group, aggregate or association membership
R = Value of the diameter and/or radius corrected for the
interstellar reddening. This remark is not used for the
values from method 6F, all corrected for the reddening.
Codes calling attention to the file of the Remarks:
A = General characteristics
E = Mean error of the apparent diameter and/or absolute radius
L = Value in the catalogue obtained by a particular law of limb
darkening; Remarks give other values of the uniform disk and/or
values corrected for the limb darkening
W = Wavelength (or bandwidth) of measurement of apparent diameter
and/or absolute radius and/or apparent magnitude when different from
the visual one.
Byte-by-byte Description of file: refs.dat
Bytes Format Units Label Explanations
1- 3 A3 --- Ref Reference code, repeated when several
lines are needed.
6- 80 A75 --- Text Text of reference, generally stars by the
"bibcode"
Byte-by-byte Description of file: notes.dat
Bytes Format Units Label Explanations
1- 9 A9 --- ID1 HD or BD number or other identification
10- 23 A14 --- ID2 Bayer,Flamsteed or other identification
25- 27 A3 --- r_Text Reference
31- 80 A50 --- Text *Text of remark
Note on Text: the following abbreviations are used:
Ro = solar radius
µ = micron
l = wavelength
Ø = angular diameter
Øud = uniform disk angular diameter
Øld = limb-darkening angular diameter
dl = delta lambda
Methods:
The methods of determination were classified as direct or indirect
methods. A more detailed subdivision is based on the physical
principles of determination. References regarding the first measures
and/or basic papers are given.
----------------------------------------------------------------------------
DIRECT METHODS
----------------------------------------------------------------------------
CODE METHOD REFERENCES
----------------------------------------------------------------------------
1 Interferometer Michelson A.A., Pease F.G.
1921ApJ....53..249M
Intensity interferometer Hanbury Brown R., Davis J. et al.
1967MNRAS.137..393B
2 Diffraction - Arnulf A. 1936, C.R.Acad.Sci.Paris 202,115
Lunar occultations Williams J.D. 1939ApJ....89..467W
3A Star scintillation - Tichov G. 1921, Mitt.Leshafts Inst.
Color changes Leningrad 2, 126
3B Star scintillation - Gezari D.Y., Lebeyrie A., Stachnik R.V.
speckle interferometry 1972ApJ...173L...1G
4 Eclipsing and spectro- Russell H.N. 1911ApJ....35..315R
scopic binaries Lehman-Filhes R. 1894, Astron.Nach. 130, 17
5 Pulsating stars Van Hoof A. 1945, Publ.Lab.Astron.Geodes.
Univ.Louvain XI, No. 100
5A Pulsating stars Wesselink A.J. 1946, Bull.Inst.Netherlands
X, 91
5B Pulsating stars Balona L.A. 1977MNRAS.178..231B
5C Pulsating stars Methods which cannot be included in the
groups 5, 5A, 5B
----------------------------------------------------------------------------
INDIRECT METHODS
----------------------------------------------------------------------------
6A Intrinsic brightness Pickering E.C. 1880, Proc.Amer.Acad.Arts &
and color Sci. 16, 1
6B " " Russell H.N. 1920PASP...32..307R
6C " " Hertzsprung E. 1922, Ann.Leiden XIV, 1
6D " " Pettit E., Nicholson S. 1928ApJ....68..279P
6E " " Chalonge D., Divan L. 1950, C.R.Acad.Sci.
Paris 231, 331
6F " " Fracassini M., Pasinetti L.E. 1967, Atti
XI Riunione Soc.Astron.It. Padova
Fracassini M., Gilardoni G., Pasinetti L.E.
1973, Astrophy.Spa.Science 22, 141
6G " " Gray D.F. 1967ApJ...149..317G
Blackwell D.E., Shallis M.J.
1977MNRAS.180..177B
6H " " Wesselink A.J. 1969MNRAS.144..297W
6I " " Barnes T.G., Evans D.S. 1976MNRAS.174..489B
6K " " Leone S. 1978, Atti Acc.Sci.Lettere, Arti
Palermo, Ser.IV, 35, 21
6L " " Walker H.J., Schonberner D.
1981A&A....97..291W
6M Fundamental stellar Various Authors
parameters
----------------------------------------------------------------------------
Acknowledgements: Livio Pastori
================================================================================
(End) Francois Ochsenbein [CDS] 18-Nov-2000
